About the Simplified MFG M1616
Send 4K video to 16 zones simultaneously
Send 4K video to 16 zones simultaneously
Are you setting up a distributed A/V system in a commercial application? This feature-packed matrix from Simplified MFG lets you send audio and 4K video from 16 HDMI sources to up to 16 TVs or monitors at the same time.
Use it in a variety of applications
Use the M1616 to display content across screens in an auditorium, office meeting room, sports bar, or other commercial space. You can show a single source on all 16 displays, or a different source on each one. Dedicated coaxial digital audio outputs for each zone pipe sound to your choice of optional external audio systems.
Flexible source selection and control
Flexible control options come courtesy of front-panel buttons, or with the included handheld remote control. This matrix switcher also has an RS-232 port for use with optional third-party control systems.
Product highlights:
- distributes audio and video from 16 HDMI sources to 16 displays
- ideal for a multi-screen setup in an auditorium, sports bar, office, or other commercial space
- passes 4K UHD (Ultra High Definition) content at up to 60 frames per second
- 18 Gbps bandwidth
HDMI features:
- compatible with HDMI sources like a computer, Blu-ray player, cable or satellite box, or security system
- HDMI 2.0 and HDCP 2.2 compliant
- 16 HDMI inputs and 16 HDMI outputs
- show a single source across all displays, or show a different source on each one
- supports resolution scaling up/down between 4K and 1080p
- supports HDR-encoded content (HDR10, HDR10+, HLG, and Dolby Vision®)
- supports a broad range of audio formats, including stereo PCM, Dolby Atmos®, and DTS:X®
- support for smart EDID ("HDMI handshake") management
Control and connections:
- RS-232C port for use with optional third-party controllers
- RJ-45 Ethernet port for connection to a local network
- browser-based setup tool for convenient settings changes
- includes IR (infrared) remote control
- 16 coaxial digital audio outputs for sending signal to an external sound system
- front-panel OLED screen displays switching status, inputs and outputs, EDID settings, and more
Dimensions and other info:
- AC power supply included
- rack-mountable with included brackets (1U)
- 17-3/8"W x 1-3/4"H" x 7-7/8"D
- weight: 6.81 lbs.
- warranty: 3 years
- MFR # M1616
