Kanto PDX700 Extra-wide full-motion mount for TVs 42"-100"

Name: Kanto PDX700
Brand: Kanto
SKU: 310PDX700
Price: 259.99 USD
Availability: InStock
Rating: 5.0 (20 reviews)

Item # 310PDX700

The PDX700 can hold a large TV as close as 2-1/2" to the wall or extend it nearly 3 feet into your room.

Front

1/13

Tilts -15° to +3° (TV not included)

2/13

Only at Crutchfield

3/13

Only at Crutchfield. No pressure. And no commissions! Our experts help you get what you need and will never upsell you. No sweat. We do the research, so you get the best info, the best instruction, and the best tech support. All for free. No regret. With 60-day price protection and returns, you can feel good about your purchase – or send it back. Legendary Service. Since 1974.

Left front

Bracket detail

Extends out to 31-1/16"

Top

Profile

Bracket detail

Hollow raceways secure cables and cords to arms

Holds TV as close as 2-1/2" to wall (TV not included)

Extends out to 31-1/16" (TV not included)

Kanto PDX700 Tilts -15° to +3° (TV not included)

Kanto PDX700 Hollow raceways secure cables and cords to arms

The PDX700 can hold a large TV as close as 2-1/2" to the wall or extend it nearly 3 feet into your room.

Item # 310PDX700

Free 1-day shipping to Virginia

Every order includes

Free lifetime tech support
60-day price-drop protection
60-day returns

In stock

$259.99

Add to cart

Add to wishlist

Compare products

Get questions answered fast & free

Expert help 400+ hours training Virginia-based

1-888-955-6000

by Crutchfield's Ralph Graves

Position your large wall-mounted TV for optimal viewing

With its articulated arms fully retracted, the Kanto PDX700 mount holds a TV of up to 100" just 2-1/2" from the wall. And it can extend as far as 31-1/16" into your room. You can swivel your mounted TV up to 90° in either direction, depending on the size of the screen. You can also tilt your mounted TV up or down to avoid glare.

This solid steel mount has a durable powder-coated finish. Hollow raceways let you keep cables and cords securely fastened to the arms. The PDX700 can support TVs with screen sizes between 42" and 100" and weighing up to 150 lbs.

Product highlights:

designed for TVs 42"-100"
supports up to 150 lbs.
fits VESA mounting hole patterns from 200 x 100mm to 700 x 500mm
articulated arms extend TV 2-1/2" to 31-1/16"
swivel range: ±90°
tilt range: -15° to +3°
hollow raceways secure cables and cords to arms
wall plate accommodates up to 24" stud spacing
stud mounting required
mounting hardware included
solid steel construction with powder-coated finish
32-1/4"W x 14"H x 2-1/2"D (up to 31-1/6"D fully extended)
weight: 37.2 lbs.
warranty: 5 years
MFR # PDX700
Item # 310PDX700

What's in the box:

Kanto PDX700 owner's manual

Wall-mount bracket w/ articulating arm assembly
Center TV bracket
2 Vertical TV brackets
2 Horizontal TV brackets
Four M5x12mm bolts
Four M5x30mm bolts
Four M6x16mm bolts
Four M6x35mm bolts
Four M8x20mm bolts
Four M8x35mm bolts
Four M8x50mm bolts
Four 5mm spacers
Four 10mm spacers
Four 14mm spacers
Four M5/M6 washers
Six M8/M10 washers
Six M10x80mm lag-bolts
6 Anchors
Hex-key
Wrench
User Manual
Mounting Template

Researched by Crutchfield's Stacey B.

Features & specs

Features
Mount Type	Wall Mount
Motion
Tilt	Yes
Swivel	Yes
Extend/Retract	Yes
Fixed	No
Roll (Level) Adjustment	Yes
Mounting Details
Wood Stud (Single)	No
Wood Stud (Dual, 16-inch)	Yes
Wood Stud (Dual, 24-inch)	Yes
Concrete Block-compatible	Yes
Recessed Housing	No
Outdoor-rated	No
Motorized	No

Product Research

Features

TV Compatibility: The Kanto PDX700 full-motion wall-mount bracket supports 42" to 100" flat-panel TVs that weigh up to 150 lbs. The TV must also meet the following VESA and screw size requirements.

VESA Sizes: 200x100mm to 700x500mm
Screw Size: M5, M6, or M8

Note: Additional hardware may be required for your specific model of TV. For example; shorter or longer screws, thicker or slimmer washers or spacers. These additional accessories can often be found at your local hardware store.

Solid Steel Construction: The Kanto PDX700 full-motion TV wall-mount bracket is constructed out of solid steel and features a powder-coated finish.

Full-Motion Design: The Kanto PDX700 features a full-motion design that accommodates a variety of TV viewing positions. The PDX700 offers extension, tilt, swivel, and roll adjustments.

Extension: Even with its low-profile design the PDX700 can extend up to 31.0625" from the wall, giving you plenty of room for tilting and swiveling your TV, or for reaching out from alcoves. Its unique tilt head is designed to nestle into the frame, letting you push your flat-panel TV within 2.4375" of the wall.
Tilt: The accessible tilt mechanism makes it easy to angle your TV up to 15° forward or 3° backward. Once you've found the best viewing angle, tighten the nuts to secure your TV in place.
Swivel: The wall-mount bracket's articulating arms allow you to pivot your TV up to 90° in either direction, depending on your TV size, allowing you to achieve the perfect viewing angle.
Roll: You can also raise and lower (+/-3°) the the sides of the TV to make sure the TV is level once it is mounted on the wall.

Integrated Cable Management: Four cable management channels are attached to the bottom of the articulating arms. These are easily accessed by loosening a screw, twisting them to the side, laying in the cable, and re-inserting the screw. Route multiple cables down one side, or power and HDMI down opposite sides - whatever works best for your specific application.

Dual-Stud Installation: The Kanto PDX700 full-motion TV wall-mount bracket can accommodate 16" or 24" stud spacing, and comes with all the hardware you need for wood stud and concrete installation. Tools required for installation include -

Drill
1/4" bit (wood), 5/8" bit (masonry)
Socket wrench
Phillips screwdriver
Hammer
Stud finder
Level
Pencil
Tape Measure
