About the Roswell R1 8 Tower

Product highlights:
- 8" marine tower speakers (pair)
- weather-protected metal housing with UV protection
- 1" silk tweeter
- built-in LED lighting (RGB controller not included)
- built-in 2 way crossover
- 360° swiveling universal clamp system with adapters
- white grilles
- sealed motor structure with Deutsch wiring harness included for water-tight connection
Specs:
- handles up to 100 watts RMS (200 watts peak power)
- frequency response: 50-20,000 Hz
- sensitivity: 90 dB
- impedance: 4 ohms
- dimensions: 9-7/8" W x 13-5/8" D x 11-1/2" H (w/bracket)
- warranty: 2 years
- MFR # C920-1710
- Item # 3511710
What's in the box:
Roswell R1 8 Tower owner's manual
If you need assistance accessing this owner's manual, please give us a call.- Two 8" tower speakers (white) w/integrated mounting clamps and attached 18" safety lanyard
- Two 30" 6-pin wiring harnessess (Deutsch connector on one end / bare-ended wire on other end)
- Four 3" clamp inserts (installed)
- Four 2.375" clamp inserts
- Four 1.90" clamp inserts
- Twelve 18 ga. crimp-connectors
- Installation instructions
More details on the Roswell R1 8 Tower

Features & specs
General | ||
---|---|---|
Tweeter Composition | Silk | |
Woofer Composition | Polypropylene | |
Woofer Surround | Rubber | |
Parts Warranty | 2 Years | |
Labor Warranty | 2 Years | |
Specifications | ||
Sensitivity |
90 dB at 1 watt | |
Style | Wakeboard tower | |
Frequency Response | 50Hz-20kHz | |
Max RMS Power Handling | 100 | |
Peak Power Handling (Watts) | 200 | |
Impedance (Ohms) | 4 |
Product Research
Features
Enclosure & Drivers: The Roswell R1 8" Tower Speakers feature a coaxially mounted 8" woofer, with a polypropylene cone and rubber surround, and a coaxially mounted 1" silk dome tweeter. A 12dB/oct. crossover is integrated into each driver for water-tight integrity. Both drivers are housed in a durable anodized aluminum enclosure with a Centrex plastic grille, designed to withstand the harsh marine environment.
Marine Tested: The R1 Series marine speakers are tested using ASTM standards, 500 hours UV exposure and 500 hours salt fog spray.
LEDs: The R1 8" Tower Speakers include built-in RGB LEDs in the back of the tweeter casing, to create a glow on the woofer cone, as well as along each side of the enclosures. Depending on what combination of LED wires is connected, they can light red, green, blue, yellow, magenta, cyan, or white. A 12 volt power supply is needed to turn the LEDs on. The LEDs can also be controlled using Roswell's RGB Remote Control (sold separately).
Wire Terminal: Each tower speaker includes a 30" 6-pin wiring harness that hold both the signal wires and LED power wires. The harnesses include a water tight Deutsch plug, for connecting to the tower speaker, with bare-ended 18 ga. wire on the other end. Both harnesses are encased in a heavy-duty rubber sheath for added protection.
Mounting: The R1 8" Tower Speakers include an attached machine-billet, 360˚ Universal Clamp for attaching the speakers to wakeboard towers and rails. Three sets of clamp inserts are provided for attaching to 1.90", 2.375", and 3.0" diameter tubing.
Klippel Verified: The Klippel distortion analyzer, a device that uses a laser and sophisticated software to do large-scale analysis of drivers in motion, lets Roswell optimize the speaker's motor structure, voice coil alignment, and suspension to yield the best possible performance.
