About the Alpine SPV-10TW-WRA

Product highlights:
- weather-resistant 1" Teteron dome tweeters (pair)
- designed for use in select 2007-up Jeep Wrangler and Gladiator vehicles
- mounting hardware included
- crossovers with tweeter level output options (0dB, +3dB)
- handles up to 75 watts RMS (225 watts peak power)
- frequency response: 2,000-22,000 Hz
- impedance: 4 ohms
- warranty: 1 year
- MFR # SPV-10TW-WRA
- Item # 500SPV10TW
- California customers: Please click here for your Proposition 65 WARNING.
What's in the box:
Alpine SPV-10TW-WRA owner's manual
If you need assistance accessing this owner's manual, please give us a call.- 2 Tweeters installed in mounting housings
- 2 Adapter plates
- Two 12" harnesses with in-line crossovers (vehicle-specific)
- 2 Alpine logo badges
- Installation manual
- Warranty information
- On-line product registration information
- Important Notice sheet
- Specs printed on box
More details on the Alpine SPV-10TW-WRA

Features & specs
General | ||
---|---|---|
Speaker Size | Vehicle-specific | |
Driver Design | 1-way | |
Woofer Design | --- | |
Woofer Material | --- | |
Woofer Surround | --- | |
Midrange Design | --- | |
Midrange Material | --- | |
Tweeter Design | Dome | |
Tweeter Material | Teteron | |
Super Tweeter Design | --- | |
Super Tweeter Material | --- | |
Impedance (Ohms) | 4 | |
Weather-resistant | Yes | |
Grilles Included | Black steel | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Sensitivity (1W at 1 meter) | N/A | |
Sensitivity at 2.83 volts | N/A | |
Frequency Response | 2000 - 22k Hz | |
Maximum RMS Wattage | 75 | |
Peak Power Handling (Watts) | 225 | |
Top-mount Depth (Inches) | 0 5/8 | |
Bottom-mount Depth (Inches) | N/A | |
Cutout Diameter or Length (inches) | 1 11/16 | |
Mounting Height (Inches) | 0.35 | |
Frame Width | 1.984 | |
Frame Length | 1.984 |
Product Research
Features
Overview: Alpine's SPV-10TW-WRA tweeters are designed for select 2007 and later Jeep Wrangler, Wrangler Unlimited, and Gladiator models (JK and JL). They fit both the dash and soundbar locations, when factory equipped.
Wiring: The tweeters plug into the outputs of the included in-line tweeter crossovers. The crossovers have two inputs (shorted together), one fits the 2007-2014 Jeep factory tweeter harness and the other fits the 2015 and later factory harness. No cutting into the factory wiring is required.
Tweeter Level: The crossovers have two tweeter level output options, 0 dB (typically used in the Tombstone style on-axis mounts) and +3 dB (often used in the 3½" locations).
Mounting: In both the dash and soundbar locations the Alpine tweeters directly replace the factory tweeters. Tweeter mounting varies based on Jeep model year and the mounting location:
- 2007-2014: The Alpine tweeters snap into the factory Tombstone housings on the dash.
- 2015 and later: The Alpine tweeters snap into the included flush mount plates and are mounted behind the factory grilles in the dash and soundbar locations.
Loading...
Loading accessories...
Customer Q&A
1 question already asked
Loading...
Loading articles...
I replaced my two Jeep (2009 JK) tweeters with these Alpine SPVs along with the 6 inch speakers and the addition of a subwoofer. The Alpine SPVs were absolutely the best addition to the sound quality. Their crisp sound and easy install made for a great addition to the Jeeps audio.
Jake Robert from Halifax, MA
