Crime Guard AL-100C

Active and Passive Operation Modes: The system may be set up to arm and disarm in response to your vehicle being locked and unlocked using your factory keyless entry remotes, or it may be set up so arming and disarming is done without input from a keyless entry system (passive operation). When programmed for passive operation, the system will arm whenever you exit the car after turning off the ignition, and it will disarm after you enter the vehicle and turn on the ignition.

Starter Interrupt Protection: When the system is armed, the included starter interrupt relay will prevent the vehicle from starting.

Door Lock Outputs: Although this system is made to work with factory keyless entry systems, the door lock outputs can be used to provide additional features. If a Crime Guard (Omega) quick interconnect doorlock harness, or another Crime Guard doorlock adapter, is not used, relays may be required (relays sold separately). When the doorlock outputs of this alarm are connected to your factory power lock system:

• the system can be programmed to lock the doors when the ignition is turned on and unlock the doors when the ignition is turned off
• if the system is disarmed and the alarm does not detect entry into the vehicle after 90 seconds, the system will lock the doors
• if the system is triggered, it will relock the doors
• if an optional sensor triggers the prewarn feature, the doors will relock
• if the automatic last door arming feature is activated, the system can be programmed to lock the doors upon arming

Valet Mode: The valet mode turns the alarm functions off, allowing a person without a keyless entry remote or code for your vehicle to operate it without interference from the alarm. While the alarm is in valet mode, the keyless entry system is unaffected, so the system can be used as normal, if desired.

Power-Maze Protection: If a thief cuts the alarm's power wire, the Power-Maze circuit provides protection by triggering the alarm system as soon as the ignition circuit is hot-wired or receives power.

Plug-in Port for Optional Sensor: A port is provided to accept the connector from an optional Crime Guard dual-zone sensor. When used with a dual-zone sensor, the alarm will give warning chirps for minor disturbances, and it will will go into full alert mode when a major disturbance is detected.

Output for Optional Siren: In addition to the output provided to sound the horn of your vehicle, this alarm includes an output for an optional siren. The horn and siren outputs can be used simultaneously to bring more attention to your vehicle, or you may use either output alone.

Alarm Condition Recall Memory: If the system enters an alarm condition, the LED will begin to flash in sequence to indicate which zone caused the trigger; the recall memory circuit can store two consecutive zone violations (if there has been more than two zones violated, the memory will recall the two most recent violations). The LED will flash once then pause when triggered by an optional sensor, three times then pause for a hood or trunk violation or four times then pause for a door circuit or current sensing violation.

Programmable Features: The following features are easily programmed using switches on the rear panel of the control module:

• Horn Chirp Confirmation: when active, the horn chirp confirmation feature will produce horn chirps when the alarm is armed/disarmed; this feature may be turned off
• Last Door Arming: when active, the last door arming feature will arm the alarm 30 seconds after the vehicle's ignition is turned off and the last door is closed; this feature may be turned off
• Doors Lock with Last Door Arming: this feature works in conjunction with the last door arming feature; when active, the doors will automatically lock after the vehicle's ignition is turned off and the last door is closed; this feature may be turned off
• Doors Lock when Ignition is Turned On: when active, this feature will lock the doors when the ignition is turned on; this feature may be turned off
• Current Sensing: when turned on, the current sensing feature causes the alarm to trigger when it is armed and it senses current draw from the battery; this feature may be turned off
• 15 Second Entry Delay: when activated, this feature allows to open a door and take up to 15 seconds to turn on the ignition before the alarm is triggered; this feature may be turned off

Dimensions

Alarm Brain (with harnesses connected): W=3.66", L=3.545", D=1.075"
