Klipsch IK-800-C Pre-construction brackets for 8" Klipsch in-ceiling speakers

Item # 714IK800C

California customers:
Please click here for your Proposition 65 warning.

4 questions - 14 answers

Item # 714IK800C

In stock
$44.99 pair

About the Klipsch IK-800-C

Loren Barstow

If you're building a new home, you can simplify the installation of the Klipsch® CDT-2800-C II, CDT-3800-C, R-1800-C or R-2800-CSM in-ceiling speakers with these pre-construction brackets. Install them before the drywall goes up to mark the speaker locations for your builder, and you won't need to cut holes later. The metal wings attach to studs and joists via screws, staples, or nails.

Product highlights:

  • compatible with CDT-2800-C, CDT-2800-C II, CDT-3800-C, CDT-5800-C, R-1800-C and R-2800-CSM speakers
  • breakaway wire tie
  • ribbed for increased rigidity
  • color-coded for easy speaker size identification
  • warranty: 60 days
  • MFR # 1001180

What's in the box:

  • 2 Green in-ceiling speaker brackets
  • Four 15.5" white perforated metal wings

Customer reviews for Klipsch IK-800-C

Loading reviews...

Average review:

5.0 out of 5 stars
20 reviews

Thanks for submitting your review

Filter by rating

Customer photos

Customer provided image, click to load a larger version.
Customer provided image, click to load a larger version.

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee review (What's this?)

Reviewed on

This review was collected as part of a promotion



Crutchfield response
Customer provided image, click to load a larger version.
<< >>

More details on the Klipsch IK-800-C

Russ B.

Product Research


Overview: The Klipsch IK-800-C installation kit offers increased mounting flexibility for all of Klipsch residential in-ceiling speakers that employ a 8.0" woofer. This installation kit also fits Klipsch's commercial IC-6T in-ceiling speakers. This installation kit design incorporates two color-coded brackets for easy speaker size identification. A flat side with a raised wall allows it to be mounted directly to a joist, making it much easier to align the speakers with other items in the ceiling. The kit also comes with four perforated metal wings that easily fasten to the studs via screws, staples or nails. Ribbed for increased rigidity, these wings enable a kit to span up to 24 inches easily. Painted white for easy marking and placement, these metal wings will fold around the edge of the studs if necessary.

Loading accessories...

Customer Q&A

4 questions already asked

Can These be used in a drop ceiling?
michael  Oct 18, 2020
4 answers
Yes. you can buy ceiling mounts that work just great. I used a threaded extension pipe 1-1/2 " that mounts very easily to the Chief mount that is designed for this method and it works great and is easy to install.
ron  Apr 26, 2021
They are not designed for a drop ceiling. The thickness of these plus the thickness of the drop ceiling tiles would most-likely be too thick for the mounting tabs of the speakers. When I've installed in a drop ceiling, I've used a thinner metal version of these (sold by another company). Hope that helps. Aloha
adam  Oct 18, 2020
I believe so. However, since a ceiling tile is loosely fit and just laying on some metal supports I would imagine that when sound is played through the speaker and it vibrates, your tile will vibrate as well.
mark  Oct 18, 2020
Hey, I installed them in a Sheetrock ceiling. The thing is they need to be screwed into a ceiling joist. If the drop is not directly attached to the joist, which I imagine it wouldn't be, you would have to fashion something to support the mount, and ultimately the speaker. The speaker is too heavy to only be supported by the drop ceiling panel. Off the top of my head either you use 2x4s attached to the joist and making their way down to just above the drop panel or maybe use some thick wire attached to the joist and then to the mount. Hope this helps.
joe  Oct 18, 2020
can this be used for a wall that already has sheet rock?
evan  May 23, 2020
8 answers
this is a pre sheetrock product to let the sheetrock.
travis  Jul 13, 2020
Unfortunately no. The included Straps actually mount to the studs and the drywall is placed over them.
jonathan  May 27, 2020
No this is used pre sheet rock
richard  May 23, 2020
No. These are meant to be installed before the sheetrock so that: a) you have perfect placement of your speakers (in-between rafters, etc.) and b) the sheetrock installers use them as a guide where to cut the holes in the sheetrock and mud around. If you already have sheetrock, you'll have to use a stud-finder for placement and the tabs/flip-out wings on ceiling speakers are used to hold onto the sheetrock. Hope this helps. Aloha
adam  May 23, 2020
No, not easily. These are designed to be used for pre-construction since they are secured with nails to the ceiling joists.
robert  May 23, 2020
The rough in bracket is designed to be used for new construction and is not needed for existing construction
james  May 23, 2020
Not effectively, and if you already have sheetrock this will not save you any trouble; just use the template provided with the speakers to cut the hole in the sheetrock ( between studs). Thising ring is designed to be fastened directly to studs, which be near
steven c  May 23, 2020
NO, i would say not. You would have to cut a hole that is big enough to get the mount inside. You can mount them without these anyway, the speakers have the wings on them that will flip out and hold on top of your sheet rock.
richard  May 23, 2020
What is the full measurement across the green rings; not the internal hole, but from one external side to the other?
merritt  May 08, 2017
1 answer
Thanks for your question. If you are measuring from the flat bottom edge to the opposite edge it would be 11.125". The other two sides are 12.5" from edge to edge. Hope this helps.
kenneth  May 08, 2017 (Staff)
