About the Bowers & Wilkins 702 S3
The flagship of the 700 series gets an upgrade
The flagship of the 700 series gets an upgrade
The advanced design of the Bowers & Wilkins 702 S3 can imbue small-group recordings with warmth, but it goes the extra mile to render big performances — symphonies, live concert recordings, etc. — with a level of accuracy and detail that almost rivals being there. The latest version improves on previous iterations with a redesigned tweeter "pod" and a new downward-firing port that improves bass response. And you can choose from three finishes: black, white, or the latest addition, mocha.
An exploded view of the redesigned "pod" that houses the 702 S3's Decoupled Carbon Dome™ tweeter.
This speaker looks different because it was designed to sound different. Bowers & Wilkins has spent decades creating and honing technology that gives their speakers a unique and beautiful "voice."
The 1" Decoupled Carbon Dome™ tweeter was purpose-built for the 700 Series to bring studio-quality sound to your home system. The top-mounted solid-body housing — borrowed from the 800 Series — is milled from a solid block of aluminum to form a structure that resists unwanted resonance. In the S3 iteration, the pod has a new, longer shape, designed to give high frequencies a more open sound.
The decoupled 6" Continuum™ cone FST™ midrange also benefits from tech developed for the high-end 800 Series. The cone's composite construction delivers precise vocals and instruments and smoother transitions.
The speaker's three 6-1/2" Aerofoil™ Profile bass cones are computer-modeled to provide the stiffness and rigidity required for deep, musical bass.
Flowport™ for better bass
The bass cones are aided by Bowers & Wilkins' Flowport technology. The 702's bass reflex enclosure features a new downward-firing port that provides natural bass response without the turbulent "chuffing" that standard ports can create.
A rich history of audio excellence
Founded in England in the 1960s, Bowers & Wilkins is known worldwide for their innovative hi-fi speaker designs and their premium headphones. Crutchfield is proud to offer a diverse selection of products from this legendary audio brand.
- 3-way, 5-driver design
- 1" Decoupled Carbon Dome™ tweeter in redesigned, top-mounted solid-body housing
- 6" Decoupled Continuum™ cone FST™ (Fixed Suspension Transducer) midrange driver
- three 6-1/2" Aerofoil™ Profile bass woofers
- frequency response: 46-28,000 Hz (±3dB)
- bass-reflex cabinet with downward-firing port
- sensitivity: 90 dB
- impedance: 8 ohms
- recommended amplifier power: 30-300 watts
- dual pairs of gold-plated binding post speaker terminals allow bi-amp/bi-wire configurations
- removable grille is magnetically attached
- included plinth and carpet spikes provide added stability
Dimensions and warranty:
- 11-7/16"W x 45-5/16"H x 16-1/8"D (including plinth)
- weight: 73.8 lbs.
- warranty: 5 years
- MFR # FP43257
What's in the box:
- Floorstanding loudspeaker
- Plinth (base)
- 2 Jumper-straps (pre-installed)
- Two-piece foam port plug
- 4 Rubber feet
- 4 Spike feet
- 4 Lock-nuts
- 4 Screws
- 4 Washers
- 4 Lock washers
- Bowers & Wilkins brochure
- Warranty Information. Online Registration Card
Customer reviews for Bowers & Wilkins 702 S3
Average review:4.0 out of 5 stars
Thanks for submitting your review
More details on the Bowers & Wilkins 702 S3
Features & specs
|Tweeter||Solid Body Hard-Dome|
|Tweeter Size (inches)||1|
|Midrange Size (inches)||6|
|Woofer Size (inches)||6.5|
|Built-in Powered Sub||No|
|Dolby Atmos Drivers||No|
|Connector Type||Binding post|
|Parts Warranty||5 Years|
|Labor Warranty||5 Years|
|Frequency Response||46-28k Hz|
|Subwoofer Amp Power||---|
1" Solid Body Tweeter-on-Top Decoupled Carbon Dome: The Bowers & Wilkins 702 S3 floorstanding loudspeaker houses a 1" Carbon Dome tweeter that utilizes a Solid Body Tweeter-on-Top design for uncompromising high performance sound that will reveal subtle nuances that you've never heard in your music before.
- 1" Decoupled Carbon Dome Tweeter: The 1" Decoupled Carbon Dome tweeter is purpose-built for the 700 Series and delivers a dramatic improvement on B&W's aluminum double dome tweeter (found in the 600 Series) by raising the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail. The tweeter is decoupled from the mounting assembly and hardware using synthetic gel to prevent any unwanted vibrations from reaching the tweeter. The result is breathtaking clarity and definition.
- Solid Body Tweeter-on-Top Design: The Solid Body Tweeter-on-Top design is borrowed from B&W 800 Series Diamond and helps the speaker convey uncanny realism, presence and transparency. Milled from a solid block of aluminum, the solid body tweeter housing design creates an acoustically optimized enclosure for the tweeter that is exceptionally inert and resistant to resonance. The result is a more natural, spacious, and open sound.
Note: There is some "play" in the tweeter housing mounted on top of the bookshelf loudspeaker enclosure. This is normal and specifically designed this way to prevent unwanted vibration between the tweeter housing and speaker enclosure.
6" Continuum Cone FST Midrange Driver with Biomimetic Suspension: Every 3-way loudspeaker in the new 700 Series (like the 702 S3) has a dedicated midrange driver using four key Bowers & Wilkins technologies - the Continuum cone, FST, Biomimetic Suspension and midrange decoupling - the latter ensuring minimal interference from the operation of the loudspeaker's bass drivers.
- Continuum Cone: The 702 S3 floorstanding loudspeaker uses a 6 " Continuum cone for its mididrange driver, borrowed from B&W's 800 Series Diamond. Thanks to its woven-coated material and composite construction, the Continuum cone provides a natural and open sound by avoiding the abrupt transitions in behavior that can impair the performance of a conventional drive unit and cause distortion. As a result, voice and instruments are delivered with purity and precision.
- FST (Fixed Suspension Transducer): The midrange driver in this loudspeaker also utilizes FST (fixed suspension transducer) technology to reduce cone distortion, incorporates a decoupled design to prevent cabinet coloration, and features a new FEA-optimised aluminium chassis to reduce vibration - all resulting in improved midrange clarity.
- Biomimetic Suspension: New to the 700 Series is B&W's Biomimetic Suspension technology that revolutionizes midrange performance by greatly reducing the unwanted air pressure and coloration that a traditional fabric spider can generate. The result is midrange transparency you have to hear to believe.
- Midrange Decoupling: The midrange driver of 700 Series 702 S3 center channel speaker features a decoupled design, developed from the 800 Series Diamond. Decoupling reduces cabinet coloration and boosts midrange clarity.
Triple 6.5" Aerofoil Profile Cone Bass Woofers: The Bowers & Wilkins 702 S3 floorstanding loudspeaker houses three 6.5" Aerofoil Profile cone bass woofers. Developed using advanced computer modeling techniques, the Aerofoil Profile cone design (adapted from B&W's 800 Series Diamond) has variable thickness, providing stiffness and rigidity where it's needed most for deep, dynamic, and accurate bass response.
Flowport Technology: The B&W 702 S3 floorstanding speaker utilizes Flowport Technology to create smooth, deep, and efficient bass response. Its bass reflex enclosure features a rear-firing, dimpled flared port that provides natural bass response without turbulent noise or distortion. If you want to reduce the volume of bass without moving the speaker further from the wall, fit the included foam plug into the rear-firing port for lesser bass response.
Note: You can adjust the floorstanding speaker's low-frequency performance using the supplied foam plug. The foam plug is two-pieces, allowing for a degree of fine-tuning using either the outer, larger-diameter piece in isolation or the two parts together. Using solely the outer, larger-diameter foam piece will deliver less bass attenuation than the complete foam plug assembly.
Acoustically Transparent Magnetic Grille: The Bowers & Wilkins 702 S3 floorstanding loudspeaker comes with an acoustically transparent magnetic grille that's easy to install, looks great, and doesn't get in the way of the sound.
Dual Binding Post Terminals: The floorstanding speaker has two sets of heavy-duty binding posts connected by jumper straps. The binding post terminals will accept bare wire, pin connectors, spade connectors, or banana plugs (single only). There are plastic inserts that will need to be removed from the binding post terminals in order to use banana plugs. Using the dual binding posts terminals, you can choose to bi-amp or bi-wire the speaker (when facing the back of the cabinet - the left set of binding posts are for the high frequency drivers; the right set of binding posts are for the low frequency drivers).
- Bi-Wiring: Bi-wiring can provide noticeable improvements in the overall transparency of your loudspeakers. Run separate speaker wires to the low & high frequency drivers from a single amplifier.
- Bi-Amping: Bi-amping allows you to use separate amplifiers for the high & low frequency sections of your loudspeaker for greater dynamic range & lower distortion. We recommend that your separate amplifiers have identical gain to preserve the speaker's voicing balance.
Note: Make sure the jumper straps between the dual binding post terminals are removed when making a bi-amp or bi-wire type of connection.
Rubber or Spike Feet: The Bowers & Wilkins 702 S3 floorstanding loudspeaker comes with a plinth (base), rubber feet, and spikes. The plinth (base) secures to the bottom of the speaker cabinet using the supplied hardware. The rubber or spike feet screw into the bottom of the plinth (base). Use the rubber feet for hardwood, laminate, tile, and vinyl flooring. Use the spike feet for carpet flooring.
- Dimensions with Rubber Feet: 11.4375" (w) x 45.3125", (h) x 16.125" (d)
- Dimensions with Spike Feet: 11.4375" (w) x 46.0625" (h) x 16.125" (d)
Note: The 704S 2 floorstanding loudspeaker should always be used with the plinth (base) and feet installed for optimum performance and proper stability.
Applications: The Bowers & Wilkins 702 S3 floorstanding is a great choice for 2ch stereo music applications, as well as multichannel home theater setups.
- Stereo Music: The floorstanding speakers should be positioned between 4.9375' and 9.875' apart at two corners of an equilateral triangle completed by the listening area at the third corner. The speakers should be approximately 1.625' away from the back wall, and at least 1.625' away from any side walls.
- Home Theater: If the floorstanding speakers are to be used for the front channels in a home theater system, position the speakers within approximately 1.625' of the sides of the TV screen to keep the sound image in scale with the visual image. The speakers should ideally be at least 1.625' away from any side walls.
Note: Moving the speaker further from the walls will generally reduce the volume of bass. Space behind the speakers will also help to create an aural impression of depth. Conversely, moving the speakers closer to the walls will increase the volume of bass.
Bowers & Wilkins 700 Series: The Bowers & Wilkins 700 Series consists of three floorstanding loudspeakers (702 / 703 / 704), three bookshelf loudspeakers (705 / 706 / 707), and two center-channel loudspeakers (HTM71 / HTM72). The 700 Series by Bowers & Wilkins brings your movie and music soundtracks to life with dynamics and details you've never heard before.
Optional Powered Subwoofers: Give your 700 Series loudspeaker setup even more impactful bass with one of Bowers & Wilkins' powered subwoofers (sold separately - see Accessories Tab).
