About the AtlasIED DT22

Product highlights:
- pre-assembled speaker unit drops into ceiling tile grids for clean installation
- 8" speaker provides clear voice paging and background music
- 2' x 2' footprint allows quick installation into acoustic tile ceilings
- white mesh grille blends in with most ceiling tiles
- external tap selector switch (located on the side of the enclosure) allows for easy system tuning
- .25, .5, 1, 2, 4 watt increments
- 8-ohm bypass
- frequency response: 85-8,000 Hz
- sensitivity: 97 dB
- 105° dispersion pattern
- UL-rated for safe installation
- 12-7/8"W x 23-7/8"H x 4-1/2"D
- weight: 9.5 lbs.
- warranty: 5 years
- MFR # DT22
- Item # 978DT22
- California customers: Please click here for your Proposition 65 WARNING.
More details on the AtlasIED DT22

Features & specs
General | ||
---|---|---|
Drivers Per Speaker | 1 | |
Woofer Size (inches) | N/A | |
Tweeter Size (inches) | N/A | |
System Frequency Response | 100-5kHz | |
Maximum SPL | --- | |
Number of Speakers Included | 2 | |
Power Handling | ||
Power Rating | 4 | |
Peak Power Rating | N | |
70V Transformer Taps (watts) | 4 watts | |
100V Transformer Taps (watts) | None | |
8-ohm Bypass | No | |
Specs | ||
Width (inches) | 23-15/16 | |
Height (inches) | 23-15/16 | |
Depth (inches) | 4-9/16 | |
Weight | 11.3 lbs |
Product Research
Features
Overview: The Atlas Sound Drop-in Speaker is designed for clear paging and background music in retail locations, such as shopping malls and department stores, where large quantities of speakers are to be used. The DT22 is an all-in-one, pre-assembled speaker package mounted to a 2' x 2' ceiling tile that simply drops into a suspended ceiling grid. The speaker has an attractive white punched metal speaker grille that blends in with most acoustic ceiling tiles.
Driver: The DT22 consists of a down-firing 8" dual-cone speaker with a 10-ounce magnet. It provides a wide 105° dispersion (2kHz octave band, -6dB).
Wiring: The DT22 drop-in speaker is equipped with a 2-way transformer that allows you to select 25V or 70.7V operation. With a screwdriver, you can select taps of 0.25, 0.5, 1, 2, and 4 watts for 25V and 70.7V systems.
Specifications:
- Frequency Response: 100Hz - 5kHz
- Sensitivity: 96dB (1W/1M)
- Dispersion Angle: 105° (-6dB, 2kHz octave band)
- Dimensions: Width=23.9" Length=23.9" Depth=4.53"
- Weight: 11.3 pounds
