About the JBL BassPro 12

Product highlights:
- powered subwoofer enclosure
- 12" sub with polypropylene cone
- built-in 150 watt RMS amplifier (450 watts peak)
- remote bass-level control included
- speaker- and line-level inputs
- 8-gauge amp wiring kit required (sold separately)
- variable low-pass crossover (40-200 Hz, 12 dB/octave)
- variable bass boost (0-12 dB at 45 Hz)
- phase switch (0°, 180°)
- frequency response: 35-120 Hz
- fuse rating: 25A
- dimensions: 22-3/8"W x 14-5/8"H x 11-7/8"D1 x 9-1/8"D2
- warranty: 1 year
- MFR # SUBBP12AM
- Item # 109GTBASSP
- California customers: Please click here for your Proposition 65 WARNING.
What's in the box:
- Powered 12" subwoofer enclosure
- Two 25A fuses (one installed in amp)
- Remote level control
- 16.5' Remote level control cable (RJ-14 connectors on both ends)
- Two 8" speaker-level input harnesses
- 1" Patch of hook-and-loop fastener w/ 3M adhesive backing
- Owner's manual
More details on the JBL BassPro 12

Features & specs
General | ||
---|---|---|
Enclosure Type | Ported | |
Finish Material | Carpet | |
Grille | None | |
Connector Type | RCA, speaker-level | |
Quick-disconnect Plug | No | |
Bi-amp Inputs | No | |
Woofer Size (inches) | 12 | |
Woofer Material | Poly | |
Passive Radiator | None | |
Width | 22-3/8" | |
Height | 14-5/8" | |
Depth | 11-7/8" | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Frequency Response | 35-120 | |
Amplifier Power (RMS) | 150 watts | |
Maximum Wattage | 450 watts | |
Sensitivity | --- | |
Impedance | --- | |
Second Voice Coil Impedance | --- | |
Crossover Point | 70-120Hz |
Product Research
Features
Amplifier: The power output from the built-in amplifier is 150 watts RMS (450 watts max). The amplifier is counter sunk into the back panel of the enclosure (the heat sink fins protrude approximately 3/8").
Signal Input: The amplifier has both speaker level (harness) and line level (RCA) inputs. The input sensitivity range is 50mV-4V for the line inputs and 400mV-16V for the speaker inputs.
Crossover: The amplifier's low pass crossover point is continuously variable from 40 to 200 Hz; the crossover slope is 12 dB/octave.
Bass Boost: The bass boost circuit provides a variable (0-12 dB) signal boost centered at 45 Hz.
Status LEDs: There are two status indicator LEDs on the amplifier. A green LED lights to indicate the amplifier is turned on and operating normally. A red LED lights to indicate the amplifier's protection circuitry has been activated. The protection circuit activates and the amplifier shuts down when the input voltage (power) is too high or too low, when the amp overheats, and when there is a short between the amp and subwoofer.
Enclosure Dimensions:
- Width: 22.375"
- Height: 14.625"
- Depth (bottom): 11.875"
- Depth (top): 9.125"
Remote Level Control: The included remote level control lets you adjust the output level of the amplifier from the front of the vehicle. It can be mounted under the dash, in the glove compartment, etc, using the supplied 3M hook-and-loop fastener, and connected with the included 16.5' connection cable terminated in RJ-14 connectors. The remote level control has the following dimensions:
- Width: 1.125"
- Height: 0.875"
- Depth: 2.125" (including the knob and cable)
Controls:
- Auto Turn-On: Two position switch; on/off; when using the speaker level inputs the amplifier will turn on automatically when it senses an input signal.
- Phase: Two position switch; 0° or 180°; the sub's phase can be easily inverted.
- Crossover Frequency: Rotary knob; set the low pass crossover point; continuously variable from 40 Hz to 200 Hz.
- Bass Boost: Rotary knob; continuously variable from 0 to +12 dB.
- Gain: Rotary knob; continuously variable from 50mV-4V (line level) or 400mV-16V (speaker level).
Connections:
- Remote Bass: RJ-14 jack for use with the included remote bass level control
- Fuse: A single 25 amp ATO style fuse protects the amplifier (spare fuse included)
- Line Input: Stereo RCA jacks (female)
- Speaker Input: 4-pin plug for use with the included high-level input harness.
- Power Input: Screw terminals for power, ground, and remote turn-on; each will accept spade terminals up to 0.33" wide (approximately).
The JBL BassPro 12 replaces these items:
- hatchback-style powered enclosure with one 12" subwoofer
- built-in 150 watt RMS amplifier (450 watts peak)
- remote bass-level control included
