About the Bazooka EL6A-HP
The affordable EL6A-HP 6-1/2" amplified Bazooka lets you add ride-filling bass to your system with a minimum of hassle. It's an ideal solution if you drive a leased vehicle, and want the thrill of powerful bass but don't want to make any modifications.
The EL6A-HP bass tube comes with a 6-1/2" woofer and a built-in amp (100 watts max power), along with a power/signal harness (16" power and ground wires, 10" turn on and speaker input leads, RCA inputs, and auto turn-on jumper), 7.5 amp fuse with holder, power rings, and mounting hardware.
An optional wired Remote Bass Control Module gives you independent in-dash volume control of your bottom end.
Details:
- 6-1/2" woofer with foam surround
- power output 100 watts max
- 85 Hz low-pass filter (18 dB/octave)
- line- and speaker-level inputs
- frequency response 39-85 Hz
- subsonic filter (12 dB/octave at 35 Hz) for improved amp efficiency
- sensitivity 103 dB
- 18-1/2"L x 6-7/8"W x 8-1/4"H
- impedance 2 ohms
- warranty: 1 year
What's in the box:
Bazooka EL6A-HP owner's manual
- 1 Amplified Bazooka tube with plastic grille; 2 Nylon mounting straps with mounting hardware (2 plastic bases and 4 self-tapping screws); Power/signal harness (consists of 16" power and ground wires / 10" turn-on and speaker-level input wires / pigtailed RCA inputs and the auto turn-on jumper); 7.5 amp blade fuse with holder; 3 Butt connectors; 1 Crimp-on ring; 1 Self-tapping screw (to attach ground lead to vehicle chassis); Manual; Phase Alert sheet; Sheet on power handling; Product Registration/Warranty card; Survey; Bazooka bumper sticker.
Reviews (0)
Customer reviews for Bazooka EL6A-HP
Loading reviews...
Thanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Bazooka EL6A-HP
Features & specs
| General | ||
|---|---|---|
| Enclosure Type | Ported | |
| Finish Material | Plastic | |
| Grille | Plastic | |
| Connector Type | Molex Plug | |
| Quick-disconnect Plug | --- | |
| Bi-amp Inputs | No | |
| Woofer Size (inches) | 6.5 | |
| Woofer Material | Paper | |
| Passive Radiator | None | |
| Width | 6-7/8" | |
| Height | 18-1/2" | |
| Depth | 8-1/4" | |
| Parts Warranty | 1 year | |
| Labor Warranty | 1 year | |
| Specifications | ||
| Frequency Response | 39-85Hz | |
| Amplifier Power (RMS) | 0 watts | |
| Maximum Wattage | 100 watts | |
| Sensitivity | 103 dB | |
| Impedance | 2 ohms | |
| Second Voice Coil Impedance | N/A | |
| Crossover Point | 85 Hz | |
Product Research
Efficiency: 103 dB rating for "typical environment", which means in-car.
Frequency Response: 39 to 85Hz. No dB variation is given.
Note: Most of the manuals for this unit incorrectly specify a frequency response of 39-120Hz. The correct frequency response is 39-85Hz
Low Pass Crossover: Fixed at 85Hz with 18dB/Octave slope.
Subsonic Filter: Fixed 12dB/Oct subsonic filter at 35Hz to conserve amplifier power.
Power Output: 100 watts maximum amplifier power.
Remote Level Control: With an optional remote level control, you to vary woofer volume. Input on the back of enclosure.
Phase Input Switch: You can easily correct an out of phase woofer. Switch on the back of enclosure.
Input Circuitry: Balanced low level (RCA level) and balanced high level (speaker level) input circuitry for increased noise reduction.
Inputs: Summed to mono internally.
Volume (level) Control: Rotary knob
Harness Connections: Support both high (speaker) level and low level (RCA) input.
Woofer Surround: Made of foam.
