HDTV antenna buying guide
Plus tips on how to find the TV signals in your area
In this article, we'll cover the advantages of over-the-air (OTA) reception and explain how to find digital TV signals in your local area. We'll talk about different types of HD antennas and tell you which ones perform best under various reception conditions.
Reasons to add a TV antenna
Even if you've never used an off-air antenna before, there are several good reasons to consider adding one to your other TV signal sources:
- OTA signals are free: Aside from the costs to purchase and install an HD antenna, receiving over-the-air TV is free.
- Local TV broadcasts are everywhere: Although big cities offer the widest selection of broadcasts, over 99% of U.S. TV households can receive at least one local station; 89% can get five or more stations.
- Over-the-air TV signals provide excellent picture quality: Cable and satellite providers offer hundreds of channels, but they employ data compression or other techniques that compromise picture quality.
Finding over-the-air TV signals
TV signal transmission is "line of sight." Getting reliable reception beyond the curvature of the earth (roughly 70 miles) is difficult. Mountains or tall buildings between the transmitter tower(s) and your home can also cause reception problems. So, the first step is to locate the transmitters for your local stations.
In addition to distance and direction to the transmitters, you need to be aware of obstacles like mountains and tall buildings.
The quick, easy way to get information that's specific to your address is to use the FCC's DTV Reception Map tool. Once you enter your address, you'll see a list of local stations. Each station has a color-coded indicator showing its signal strength.
To see where the transmitters are located use the TV Fool site.
Now that you know the direction and signal quality of the local TV stations you can receive, let's see which type of TV antenna will work best for you.
TV antenna basics
No one antenna or antenna type will deliver excellent TV reception in every location. The main factors determining reception are the distance and direction from the TV station transmitters to your home. The transmitter's power and the height of its tower also matter.
If you live within a few miles of the transmitter, and the signal path is relatively unobstructed, you may be able to get solid reception using a small indoor antenna.
But as you move farther away, getting usable signal strength becomes trickier. This is where careful HD antenna selection and installation become essential.
TV signals actually bend a bit in the atmosphere, which can extend reception range beyond the usual line-of-sight limit of 70 miles.
The information below will help you zero in on the type(s) of antenna that should work best for you. Keep in mind that even in the same neighborhood reception conditions can vary from house to house. So we recommend purchasing your TV antenna from a dealer who offers no-hassle returns with a money-back guarantee.
VHF and UHF
Like analog signals, digital TV signals can be broadcast over two different frequency ranges: VHF (Very High Frequency) and UHF (Ultra High Frequency). The VHF channel range is 2-13 — "low-band" VHF is channels 2-6; "high-band" VHF is channels 7-13. The UHF channel range is 14-51.
There are nearly 1,800 full-power TV stations across the U.S., including 1300+ UHF, around 450 high-band VHF, and fewer than 50 low-band VHF. If some of the local stations you want to receive are below 14 — especially channels 2-6 — you'll need a VHF/UHF antenna. We carry several models that cover the entire VHF/UHF range, channels 2-51.
What's the difference between UHF and VHF antennas? Mainly size. Antenna elements are based on the size of the waves they're designed to receive, and VHF frequencies are lower so the waves are longer, requiring a larger antenna surface to receive them.
Directional vs. multi-directional TV antennas
Antennas described as "directional" are designed to receive signals from one direction. "Multidirectional" or "omni-directional" antennas are able to receive signals from multiple directions.
Directional HD antennas are able to pull in signals from greater distances, and because they "see" in only one direction they are resistant to noise and "multipath distortion" (a problem created when an antenna receives reflections of the desired signal).
Because multidirectional antennas "see" in many directions they are more likely to pick up noise, interference, and multipath distortion.
When TV signals bounce off objects on their way from the transmitter to your HDTV antenna they create reflections, which your HD antenna also picks up. These reflections can cause "multipath distortion."
If you used the TV Fool website to locate your desired stations, you should have an accurate picture of their direction in relation to your home. If all of those stations are transmitting from an area covering a range of 20° or less, you can probably receive them using a directional antenna.
If the transmitters are positioned more than 20° apart, try a multi-directional antenna. As an alternative to a multi-directional antenna, you might consider combining a directional antenna with a rotor, which lets you remotely rotate the antenna to pick up stations in multiple directions.
Indoor vs. outdoor antennas
The One For All Suburbs Ultimate indoor antenna is decor-friendly and mounts easily to a wall, a window, or almost anywhere.
Indoor antennas are generally small, lightweight, and simple to connect to your TV. While many people place this type of HD antenna on or near the TV for convenience, you'll generally get the best reception if you place it fairly high on a wall or close to a window.
Outdoor antennas tend to be significantly larger and are intended for roof- or attic-mounting.
In general, the larger an HDTV antenna's surface area is, the stronger the signal it will provide. The relative strength of the signal an antenna can deliver to a tuner is referred to as "gain" and is measured in decibels (dB). The higher the dB rating, the greater the gain.
Amplified vs. non-amplified antennas
One way to help HDTV antennas overcome size or height disadvantages, or otherwise improve reception, is by amplifying the signal. The amplifier can be built in, as it is in many indoor antennas, or it can be a separate device. The potential drawbacks of amplifiers are that they amplify noise along with the signal, and they can be overdriven by strong signals, which can make reception worse.
Other good antenna info resources
If you know of any neighbors who are using an HD antenna, find out what type/model it is and how well it performs. You could also try calling local TV stations with your antenna questions. It's definitely in their interest to help their viewers improve reception.
The AVS Forum's local HDTV message boards are also an excellent source for info on digital TV reception; they're loaded with great suggestions and solutions to particular reception problems in locations ranging from big cities to small towns and rural communities.
To learn more about ATSC 3.0, the newest OTA broadcast standard, read our NextGen TV FAQ.
